Brand: Shengshi Weiye	Model: SYE-3000D	Test machine level:Level 1
Maximum compressive test force:3000kN	Compression space (mm):340	Piston stroke (mm): 80
Upper pressure plate size (mm): 265×265	Machine weight (kg):1500	Machine power (KW):2.0
Lower pressure plate size (mm): 360×285	Main machine size (mm): 1000×500×1500

SYE-3000D electro-hydraulic pressure testing machine is driven by hydraulic power source and uses intelligent measurement and control instruments to collect and process test data. It consists of four parts: test host, oil source (hydraulic power source), measurement and control system, and test equipment. The maximum test force is 3000kN, and the accuracy level of the test machine is better than level 1.
SYE-3000D electro-hydraulic pressure testing machine can meet the national standard test requirements for bricks, concrete, cement and other materials, with manual loading, digital display of loading force value and loading speed value.
The test machine is a main engine and oil source integrated structure; it is suitable for compression test of cement and concrete, and can meet the splitting test, flexural test, and static elastic modulus test of concrete with appropriate fixtures and measuring devices.
The test machine and its accessories meet the requirements of GB/T2611 and GB/T3159 standards.
